Adet bazlı fiyat
- 1+ adet$39.09
- 10+ adet$36.88
- 100+ adet$34.79
- 500+ adet$32.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- RoHS Compliant
- Center Gender
- Female to Male
- Yayın Yılı
- 2016
- Contact Plating
- Silver
- Conversion Type
- Between Series
- Ambalaj
- Bulk
- Fastening Type
- Threaded, Threaded
- Contact Materials
- Copper
- Mating Cycles
- 500
- Parça Durumu
- Active
- Body Material
- Brass
- Çalışma Sıcaklığı
- -65°C~165°C
- Empedans
- 50Ohm
- Connector Type
- Coaxial
- Adapter Series
- 7/16 DIN to 4.3/10
- Center Contact Plating
- Silver
- Body Finish
- White Bronze
- Frequencymax
- 6GHz
- Özellikler
- Low PIM
- Convert From Adapter End
- 7/16 Plug, Male Pin
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Reach Svhc
- Unknown
- Nem Hassasiyeti (MSL)
- Not Applicable
- Center Contact Material
- Beryllium Copper
- Adapter Type
- Plug to Jack
- Body Plating
- Bronze
- Style
- Straight
- Convert To Adapter End
- 4.3/10 Jack, Female Socket
- Montaj Tipi
- Free Hanging (In-Line)
- Fabrika Tedarik Süresi
- 9 Weeks
- Montaj
- Free Hanging
