Adet bazlı fiyat
- 1+ adet$15.34
- 10+ adet$14.48
- 100+ adet$13.66
- 500+ adet$12.88
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- 316
- Body Material
- Brass
- Option
- WITH CABLE ASSEMBLY
- Cable Group
- RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
- Body Plating
- Bronze
- Connector Style
- QMA
- Connector Type
- Jack, Female Socket
- Montaj
- Bulkhead, Front Side Nut, Panel
- Coupling Type
- THREADED
- Yayın Yılı
- 2004
- Orientation
- Straight
- Parça Durumu
- Active
- Frequencymax
- 11GHz
- Frekans
- 6GHz
- Mounting Feature
- Bulkhead - Front Side Nut
- Iec Conformance
- NO
- Radyasyon Dayanımı
- No
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Includes
- 4 pcs - 1 Connector, 1 Contact, 1 Lockwasher, 1 Nut
- Ambalaj
- Bulk
- Mil Conformance
- NO
- Polarity
- Standard
- Fastening Type
- Snap-On
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Center Contact Material
- Beryllium Copper
- Montaj Tipi
- Panel Mount
- Number Of Ports
- 1
- Contact Termination
- Solder
- ECCN Kodu
- EAR99
- Contact Materials
- Copper
- Shield Termination
- Crimp
- Center Contact Plating
- Gold
- Nominal Gerilim
- 480V
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e4
- Din Conformance
- NO
- Fabrika Tedarik Süresi
- 9 Weeks
- Body Finish
- White Bronze
- Kurşunsuz
- Lead Free
