Adet bazlı fiyat
- 1+ adet$10.38
- 10+ adet$9.79
- 100+ adet$9.24
- 500+ adet$8.71
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Snap-On
- Mil Conformance
- NO
- Iec Conformance
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Material
- Beryllium Copper
- Empedans
- 50Ohm
- Parça Durumu
- Active
- JESD-609 Kodu
- e4
- Filter Feature
- NO
- Orientation
- Straight
- Ambalaj
- Bulk
- Frekans
- 6GHz
- Depth
- 6mm
- Polarity
- Standard
- Montaj
- PCB, Through Hole
- Number Of Ports
- 1
- Center Contact Material
- Beryllium Copper
- Contact Materials
- Copper
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -40°C~155°C
- Insertion Loss
- 0.1dB
- Vswr
- 1.3
- Option
- GENERAL PURPOSE
- Radyasyon Dayanımı
- No
- Din Conformance
- NO
- Center Contact Plating
- Gold
- Contact Termination
- Solder
- Yayın Yılı
- 2006
- Insulation Materials
- Polytetrafluoroethylene
- Mating Cycles
- 500
- Connector Type
- Jack, Female Socket
- Connector Style
- MCX
- Özellikler
- Non-Magnetic
- Uzunluk
- 6mm
- Fabrika Tedarik Süresi
- 9 Weeks
