Adet bazlı fiyat
- 1+ adet$9.09
- 10+ adet$8.58
- 100+ adet$8.09
- 500+ adet$7.63
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Orientation
- Straight
- Total Number Of Contacts
- 1
- Frekans
- 6GHz
- Kılıf / Paket
- 316
- Ambalaj
- Bulk
- JESD-609 Kodu
- e4
- Contact Style
- COAX
- Parça Durumu
- Active
- Empedans
- 50Ohm
- Iec Conformance
- NO
- Body Material
- Brass
- Cable Group
- RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Montaj Tipi
- Panel Mount
- Mil Conformance
- NO
- Mounting Feature
- Bulkhead - Front Side Nut
- Fastening Type
- Snap-On
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Shield Termination
- Crimp
- Gender
- Male
- Çalışma Sıcaklığı
- -65°C~165°C
- RoHS Durumu
- RoHS Compliant
- Number Of Ports
- 1
- Montaj
- Bulkhead, Cable, Front Side Nut, Panel
- Reliability
- COMMERCIAL
- Polarity
- Standard
- Contact Materials
- Copper
- Center Contact Material
- Beryllium Copper
- Yayın Yılı
- 2002
- Contact Termination
- Solder
- Insulation Materials
- Teflon
- Center Contact Plating
- Gold
- Radyasyon Dayanımı
- No
- Option
- GENERAL PURPOSE
- Vswr
- 1
- Din Conformance
- NO
- Fabrika Tedarik Süresi
- 9 Weeks
- Insulation Resistance
- 5GOhm
- Insertion Loss Db
- 0.1 dB
