Adet bazlı fiyat
- 1+ adet$14.86
- 10+ adet$14.02
- 100+ adet$13.23
- 500+ adet$12.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Bodyshell Style
- JACK
- Insertion Forcemax
- 26.688 N
- Contact Resistance
- 5mOhm
- Center Contact Plating
- Gold
- Insulation Materials
- Polytetrafluoroethylene
- Yayın Yılı
- 2000
- Contact Termination
- Solder
- Din Conformance
- NO
- Radyasyon Dayanımı
- No
- Option
- GENERAL PURPOSE
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Style
- MCX
- Mating Cycles
- 500
- Connector Type
- Receptacle, Female Socket
- Uzunluk
- 5.89mm
- Frequencymax
- 2GHz
- Insulation Resistance
- 5kOhm
- Insertion Loss Db
- 0.1 dB
- Contact Style
- COAX
- Parça Durumu
- Active
- Empedans
- 50Ohm
- Frekans
- 6GHz
- Total Number Of Contacts
- 1
- Ambalaj
- Bulk
- Filter Feature
- NO
- Orientation
- Straight
- Nominal Gerilim
- 500V
- Mil Conformance
- NO
- Fastening Type
- Snap-On
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Surface Mount
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Material
- Brass
- Iec Conformance
- NO
- Çalışma Sıcaklığı
- -40°C~85°C
- RoHS Durumu
- RoHS Compliant
- Gender
- Female
- Depth
- 5.89mm
- Contact Materials
- Copper
- Center Contact Material
- Beryllium Copper
