Adet bazlı fiyat
- 1+ adet$21.75
- 10+ adet$20.52
- 100+ adet$19.36
- 500+ adet$18.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Radyasyon Dayanımı
- No
- Empedans
- 50Ohm
- Insertion Loss
- 0.6dB
- Nominal Gerilim
- 335V
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Center Contact Material
- Beryllium Copper
- Housing Color
- Silver
- Orientation
- Right Angle
- Contact Termination
- Solder
- Ambalaj
- Bulk
- Connector Style
- SMB
- Din Conformance
- NO
- Reliability
- COMMERCIAL
- Contact Style
- COAX
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Shield Termination
- Crimp
- Body Finish
- White Bronze
- Number Of Ports
- 1
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Material
- Beryllium Copper
- Total Number Of Contacts
- 1
- Özellikler
- Non-Magnetic
- Includes
- 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Depth
- 0.523 inch
- Fastening Type
- Snap-On
- Body Plating
- Bronze
- Fabrika Tedarik Süresi
- 9 Weeks
- Iec Conformance
- NO
- Option
- GENERAL PURPOSE
- Vswr
- 1.5
- Polarity
- Standard
- Mating Cycles
- 500
- Cable Group
- RG-178, 178A, 178B, 196, 196A, M17/93-RG178
- JESD-609 Kodu
- e4
- Filter Feature
- NO
- Contact Materials
- Brass, Copper
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Yayın Yılı
- 2006
