Teknik Özellikler
- Connector Type
- Plug, Female Socket
- Mil Conformance
- NO
- Çalışma Sıcaklığı
- -65°C~165°C
- Frekans
- 4GHz
- Montaj
- Cable, Free Hanging
- Yayın Yılı
- 2001
- Center Contact Plating
- Gold
- Cable Group
- Belden 735A
- JESD-609 Kodu
- e4
- Filter Feature
- NO
- Contact Materials
- Copper
- Insulation Materials
- TFE FLUOROCARBON
- Option
- GENERAL PURPOSE
- Polarity
- Standard
- Mating Cycles
- 500
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- Fastening Type
- Snap-On
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Includes
- 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
- Body Material
- Zinc
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Finish
- Nickel
- Number Of Ports
- 1
- Shield Termination
- Crimp
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Din Conformance
- NO
- Ambalaj
- Bulk
- Connector Style
- SMB
- Orientation
- Right Angle
- Contact Termination
- Solder
- Housing Color
- Silver
- Center Contact Material
- Beryllium Copper
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 335V
- Radyasyon Dayanımı
- No
- Empedans
- 75Ohm
- Insertion Loss
- 0.6dB
