Adet bazlı fiyat
- 1+ adet$9.67
- 10+ adet$9.12
- 100+ adet$8.61
- 500+ adet$8.12
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Ports
- 1
- Terminal
- Solder
- Reach Svhc
- Unknown
- Body Material
- Brass
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Montaj Tipi
- Panel Mount
- Din Conformance
- NO
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Connector Style
- SMB
- Orientation
- Straight
- Contact Termination
- Crimp
- Nominal Gerilim
- 335V
- Empedans
- 50Ohm
- Radyasyon Dayanımı
- No
- Insertion Loss
- 0.3dB
- Mounting Feature
- Bulkhead - Front Side Nut
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Montaj
- Bulkhead, Front Side Nut, Panel
- Connector Type
- Jack, Male Pin
- Mil Conformance
- YES
- Çalışma Sıcaklığı
- -65°C~165°C
- Frekans
- 4GHz
- Option
- GENERAL PURPOSE
- Gender
- Male
- Mating Cycles
- 500
- Polarity
- Standard
- Vswr
- 1.5
- Iec Conformance
- NO
- Yayın Yılı
- 2003
- Center Contact Plating
- Gold
- JESD-609 Kodu
- e4
- Cable Group
- RG-174, 188, 188A, 316
- Insulation Materials
- Tetrafluoroethylene
- Contact Materials
- Brass, Copper
- Filter Feature
- NO
- Fastening Type
- Snap-On
- Insulation Resistance
- 1GOhm
- Fabrika Tedarik Süresi
- 9 Weeks
