Adet bazlı fiyat
- 1+ adet$10.94
- 10+ adet$10.32
- 100+ adet$9.74
- 500+ adet$9.19
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insertion Loss
- 0.3dB
- Empedans
- 50Ohm
- Nominal Gerilim
- 335V
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Mounting Feature
- Bulkhead - Rear Side Nut
- Contact Resistance
- 6mOhm
- Orientation
- Straight
- Contact Termination
- Solder Cup
- Connector Style
- SMB
- Ambalaj
- Bulk
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
- Contact Style
- COAX
- Din Conformance
- NO
- Montaj Tipi
- Panel Mount
- Shield Termination
- Solder
- Reach Svhc
- Unknown
- Number Of Ports
- 1
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Material
- Brass
- Total Number Of Contacts
- 1
- Uzunluk
- 15.1mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Weight
- 22.700002g
- Fastening Type
- Snap-On
- Fabrika Tedarik Süresi
- 9 Weeks
- Insulation Resistance
- 1GOhm
- Iec Conformance
- NO
- Mating Cycles
- 500
- Polarity
- Standard
- Vswr
- 1.5
- Gender
- Male
- Option
- GENERAL PURPOSE
- Insulation Materials
- Tetrafluoroethylene
- Filter Feature
- NO
- Contact Materials
- Brass, Copper
- JESD-609 Kodu
- e4
- Yayın Yılı
- 2001
