Adet bazlı fiyat
- 1+ adet$24.07
- 10+ adet$22.71
- 100+ adet$21.42
- 500+ adet$20.21
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Shield Termination
- Crimp
- Montaj Tipi
- Free Hanging (In-Line)
- Din Conformance
- NO
- Body Material
- Brass
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Number Of Ports
- 1
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 335V
- Insertion Loss
- 0.3dB
- Empedans
- 50Ohm
- Radyasyon Dayanımı
- No
- Connector Style
- SMB
- Ambalaj
- Bulk
- Orientation
- Straight
- Contact Termination
- Solder
- Center Contact Material
- Beryllium Copper
- Yayın Yılı
- 2001
- Center Contact Plating
- Gold
- Insulation Materials
- Tetrafluoroethylene
- Contact Materials
- Copper
- Filter Feature
- NO
- JESD-609 Kodu
- e4
- Cable Group
- RG-316 Double Braid
- Gender
- Female
- Mating Cycles
- 500
- Polarity
- Standard
- Vswr
- 1.5
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Frekans
- 4GHz
- Çalışma Sıcaklığı
- -65°C~165°C
- Mil Conformance
- YES
- Connector Type
- Plug, Female Socket
- Montaj
- Cable, Free Hanging
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Uzunluk
- 25.9mm
- Includes
- 5 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Insulator, 1 Rear Body
- Fabrika Tedarik Süresi
- 9 Weeks
