Adet bazlı fiyat
- 1+ adet$19.41
- 10+ adet$18.31
- 100+ adet$17.28
- 500+ adet$16.30
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Panel Mount, Through Hole
- Reliability
- COMMERCIAL
- Contact Style
- COAX
- Din Conformance
- NO
- Body Material
- Brass
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Number Of Ports
- 1
- Body Finish
- Nickel
- Parça Durumu
- Active
- Mounting Feature
- Bulkhead - Front Side Nut
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 335V
- Insertion Loss
- 0.3dB
- Radyasyon Dayanımı
- No
- Empedans
- 50Ohm
- Connector Style
- SMB
- Ambalaj
- Bulk
- Orientation
- Straight
- Contact Termination
- Solder
- Housing Color
- Silver
- Center Contact Plating
- Gold
- Yayın Yılı
- 2001
- Contact Materials
- Brass, Copper
- Filter Feature
- NO
- Insulation Materials
- Tetrafluoroethylene
- JESD-609 Kodu
- e4
- Vswr
- 1.5
- Mating Cycles
- 500
- Gender
- Male
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Frekans
- 4GHz
- Connector Type
- Receptacle, Male Pin
- Mil Conformance
- YES
- Çalışma Sıcaklığı
- -65°C~165°C
- Montaj
- Bulkhead, Panel, Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- Total Number Of Contacts
- 1
