Adet bazlı fiyat
- 1+ adet$12.23
- 10+ adet$11.54
- 100+ adet$10.89
- 500+ adet$10.27
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Shield Termination
- Crimp
- Din Conformance
- NO
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Free Hanging (In-Line)
- Frequencymax
- 4GHz
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Material
- Brass
- Reach Svhc
- Unknown
- Body Finish
- Nickel
- Number Of Ports
- 1
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Radyasyon Dayanımı
- No
- Empedans
- 50Ohm
- Insertion Loss
- 0.3dB
- Nominal Gerilim
- 335V
- Orientation
- Straight
- Contact Termination
- Solder
- Ambalaj
- Bulk
- Connector Style
- SMB
- Center Contact Material
- Beryllium Copper
- Housing Color
- Silver
- Cable Group
- RG-174, 179, 187, 188, 316
- JESD-609 Kodu
- e4
- Insulation Materials
- Tetrafluoroethylene
- Contact Materials
- Copper
- Filter Feature
- NO
- Yayın Yılı
- 2001
- Center Contact Plating
- Gold
- Iec Conformance
- NO
- Option
- GENERAL PURPOSE
- Vswr
- 1.5
- Polarity
- Standard
- Mating Cycles
- 500
- Gender
- Female
- Connector Type
- Plug, Female Socket
- Mil Conformance
- YES
- Çalışma Sıcaklığı
- -65°C~165°C
- Frekans
- 4Hz
- Montaj
- Cable, Free Hanging
