Adet bazlı fiyat
- 1+ adet$16.54
- 10+ adet$15.61
- 100+ adet$14.72
- 500+ adet$13.89
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 335V
- Empedans
- 50Ohm
- Radyasyon Dayanımı
- No
- Insertion Loss
- 0.6dB
- Ambalaj
- Bulk
- Connector Style
- SMB
- Orientation
- Right Angle
- Contact Termination
- Solder
- Housing Color
- Silver
- Center Contact Material
- Beryllium Copper
- Shield Termination
- Crimp
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Frequencymax
- 10GHz
- Din Conformance
- NO
- Body Material
- Brass
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Body Finish
- Nickel
- Number Of Ports
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Includes
- 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
- Fabrika Tedarik Süresi
- 9 Weeks
- Fastening Type
- Snap-On
- Yayın Yılı
- 2001
- Center Contact Plating
- Gold
- JESD-609 Kodu
- e4
- Cable Group
- RG-316 Double Braid
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Contact Materials
- Copper
- Filter Feature
- NO
- Option
- GENERAL PURPOSE
- Gender
- Male
- Mating Cycles
- 500
- Polarity
- Standard
- Vswr
- 1.5
- Iec Conformance
- NO
- Frekans
- 4GHz
- Çalışma Sıcaklığı
- -65°C~165°C
- Mil Conformance
- YES
