Adet bazlı fiyat
- 1+ adet$33.67
- 10+ adet$31.76
- 100+ adet$29.97
- 500+ adet$28.27
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Iec Conformance
- NO
- Center Contact Material
- Beryllium Copper
- Center Gender
- Female to Female
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- Additional Feature
- CAPTIVE CONTACT
- Montaj Tipi
- Panel Mount
- Adapter Type
- Jack to Jack
- Conversion Type
- Same Series
- Yayın Yılı
- 2001
- Frequencymax
- 12.4GHz
- HTS Kodu
- 8536.69.80.00
- Style
- Straight
- Frekans
- 18GHz
- Çalışma Sıcaklığı
- -65°C~165°C
- Kılıf / Paket
- SMA
- Gender
- Female
- Mounting Feature
- Bulkhead
- Convert To Adapter End
- SMA Jack, Female Socket
- Connector Type
- Coaxial
- Fabrika Tedarik Süresi
- 9 Weeks
- Convert From Adapter End
- SMA Jack, Female Socket
- Center Contact Plating
- Gold
- Ambalaj
- Bulk
- Fastening Type
- Threaded, Threaded
- Filter Feature
- NO
- Din Conformance
- NO
- Insulation Materials
- Tetrafluoroethylene
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 2100VAC V
- Body Material
- Stainless Steel
- Radyasyon Dayanımı
- No
- Mil Conformance
- NO
- Option
- GENERAL PURPOSE
- Reliability
- COMMERCIAL
- Empedans
- 50Ohm
- Insertion Loss
- 0.13 dB
- Depth
- 9.5mm
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Montaj
- Bulkhead, Panel
- Adapter Series
- SMA to SMA
