Adet bazlı fiyat
- 1+ adet$4.41
- 10+ adet$4.16
- 100+ adet$3.92
- 500+ adet$3.70
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Iec Conformance
- NO
- Connector Style
- F Type
- Option
- GENERAL PURPOSE
- Connector Type
- Jack, Female Socket
- Dielectric Material
- Polypropylene (PP)
- Mating Cycles
- 500
- Gender
- Male
- Filter Feature
- NO
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Cable Group
- RG-179, 179A, 179B, 187, 187A, Belden 9221, M17/94-RG179
- Montaj Tipi
- Panel Mount
- Din Conformance
- NO
- Number Of Ports
- 1
- Nominal Gerilim
- 500V
- Frequencymax
- 2GHz
- Fabrika Tedarik Süresi
- 9 Weeks
- Mounting Feature
- Bulkhead - Front Side Nut
- Includes
- 4 pcs - 1 Connector, 1 Ferrule, 1 Lockwasher, 1 Nut
- Contact Termination
- Solder
- Uzunluk
- 31.5mm
- Yayın Yılı
- 2010
- Body Material
- Brass
- Çalışma Sıcaklığı
- -40°C~60°C
- Montaj
- Bulkhead, Front Side Nut, Panel
- Housing Color
- Silver
- Frekans
- 1GHz
- Weight
- 7.700014g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Shield Termination
- Crimp
- Insulation Materials
- Polypropylene
- Fastening Type
- Threaded
- Empedans
- 75Ohm
- Radyasyon Dayanımı
- No
- Mil Conformance
- NO
- Contact Plating
- Tin
- JESD-609 Kodu
- e3
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Contact Finish Mating
- TIN
