Adet bazlı fiyat
- 1+ adet$9.04
- 10+ adet$8.53
- 100+ adet$8.04
- 500+ adet$7.59
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 2008
- Body Material
- Brass
- Terminal
- Crimp
- Mating Cycles
- 500
- Contact Termination
- Crimp
- Montaj Tipi
- Panel Mount
- Center Contact Material
- Phosphor Bronze
- Fastening Type
- Threaded
- Radyasyon Dayanımı
- No
- Empedans
- 50Ohm
- Center Contact Plating
- Gold
- Weight
- 38.340008g
- Frequencymax
- 11GHz
- Frekans
- 11GHz
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -65°C~165°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Min. Çalışma Sıcaklığı
- -65°C
- Body Finish
- Nickel
- Contact Materials
- Bronze, Copper
- Ingress Protection
- Weatherproof
- Maks. Çalışma Sıcaklığı
- 165°C
- Housing Color
- Silver
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nominal Gerilim
- 1500V
- Montaj
- Bulkhead, Front Side Nut, Panel
- Ambalaj
- Bulk
- Cable Group
- Belden 9913, 9914, LMR-400
- Parça Durumu
- Active
- Mounting Feature
- Bulkhead - Front Side Nut
- Connector Style
- N Type
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Body Plating
- Nickel
- Connector Type
- Jack, Female Socket
- Contact Plating
- Nickel
- Includes
- 6 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Gasket, 1 Lockwasher, 1 Nut
- Number Of Ports
- 1
- Shield Termination
- Crimp
- Insertion Loss
- 0.15dB
