Adet bazlı fiyat
- 1+ adet$9.29
- 10+ adet$8.77
- 100+ adet$8.27
- 500+ adet$7.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Materials
- Polytetrafluoroethylene
- Parça Durumu
- Active
- Cable Group
- RG-55, 142, 223, 400
- Depth
- 25.4mm
- Ambalaj
- Bulk
- Mounting Feature
- Flange
- Connector Style
- N Type
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Includes
- 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
- Contact Plating
- Gold
- Body Plating
- Nickel
- Connector Type
- Jack, Female Socket
- Insulation Resistance
- 5GOhm
- Number Of Ports
- 1
- Shield Termination
- Crimp
- Insertion Loss
- 0.15dB
- Uzunluk
- 31.9mm
- Contact Termination
- Crimp
- Montaj Tipi
- Panel Mount
- Terminal
- Crimp
- Mating Cycles
- 500
- Body Material
- Brass
- Yayın Yılı
- 2007
- Empedans
- 50Ohm
- Radyasyon Dayanımı
- No
- Fastening Type
- Threaded
- Center Contact Material
- Phosphor Bronze
- Min. Çalışma Sıcaklığı
- -65°C
- Body Finish
- White Bronze
- Çalışma Sıcaklığı
- -65°C~165°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Plating
- Gold
- Weight
- 36.00001g
- Frekans
- 11GHz
- Frequencymax
- 11GHz
- Fabrika Tedarik Süresi
- 9 Weeks
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nominal Gerilim
- 1500V
- Montaj
- Bulkhead, Flanges, Panel
