Adet bazlı fiyat
- 1+ adet$10.71
- 10+ adet$10.11
- 100+ adet$9.53
- 500+ adet$8.99
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Center Contact Material
- Beryllium Copper
- Fastening Type
- Threaded
- Empedans
- 50Ohm
- Yayın Yılı
- 2001
- Body Material
- Brass
- Terminal
- Solder
- Mating Cycles
- 500
- Montaj Tipi
- Panel Mount
- Contact Termination
- Solder
- Contact Materials
- Bronze, Copper
- Ingress Protection
- Weatherproof
- Kurşunsuz
- Lead Free
- Housing Color
- Silver
- Maks. Çalışma Sıcaklığı
- 165°C
- Montaj
- Bulkhead, Front Side Nut, Panel
- Nominal Gerilim
- 1500V
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Fabrika Tedarik Süresi
- 10 Weeks
- Frekans
- 11GHz
- Frequencymax
- 11GHz
- Weight
- 35.699987g
- Center Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -65°C~165°C
- Min. Çalışma Sıcaklığı
- -65°C
- Body Finish
- White Bronze
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Connector Style
- N Type
- Mounting Feature
- Bulkhead - Front Side Nut
- Ambalaj
- Bulk
- Cable Group
- RG-401 (.250 Semi Rigid)
- Parça Durumu
- Active
- Insulation Materials
- Polytetrafluoroethylene
- Uzunluk
- 26.7mm
- Insertion Loss
- 0.15dB
- Shield Termination
- Solder
- Number Of Ports
- 1
- Connector Type
- Jack, Female Socket
- Body Plating
- Bronze
