Adet bazlı fiyat
- 1+ adet$5.88
- 10+ adet$5.54
- 100+ adet$5.23
- 500+ adet$4.93
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Style
- N Type
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Insulation Materials
- Polytetrafluoroethylene
- Ambalaj
- Bulk
- Cable Group
- RG-401 (.250 Semi Rigid)
- JESD-609 Kodu
- e4
- Number Of Ports
- 1
- Shield Termination
- Solder
- Insertion Loss
- 0.15dB
- Insulation Resistance
- 5GOhm
- Uzunluk
- 24.5mm
- Includes
- 2 pcs - 1 Connector, 1 Contact
- Vswr
- 1.3
- Body Plating
- Bronze
- Option
- GENERAL PURPOSE
- Connector Type
- Plug, Male Pin
- Din Conformance
- NO
- Radyasyon Dayanımı
- No
- Empedans
- 50Ohm
- Fastening Type
- Threaded
- Mating Cycles
- 500
- Contact Termination
- Crimp or Solder
- Montaj Tipi
- Free Hanging (In-Line)
- Iec Conformance
- NO
- Yayın Yılı
- 2001
- Body Material
- Brass
- Housing Color
- Silver
- Nominal Gerilim
- 1500V
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Montaj
- Bulkhead, Cable, Free Hanging
- Diameter Inside
- 6.4 mm
- Kurşunsuz
- Lead Free
- Body Finish
- White Bronze
- Filter Feature
- NO
- Weight
- 28.349523g
- Center Contact Plating
- Gold
- Fabrika Tedarik Süresi
- 8 Weeks
- Frekans
- 11GHz
