Adet bazlı fiyat
- 1+ adet$8.27
- 10+ adet$7.80
- 100+ adet$7.36
- 500+ adet$6.94
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Materials
- Polytetrafluoroethylene
- Mating Cycles
- 500
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Option
- GENERAL PURPOSE
- Connector Style
- SMB, Mini
- Uzunluk
- 14.7mm
- Montaj
- Cable, Free Hanging
- Cable Group
- AT&T 735A
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Orientation
- Right Angle
- JESD-609 Kodu
- e4
- Center Contact Plating
- Gold
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -65°C~165°C
- Body Material
- Brass
- Radyasyon Dayanımı
- No
- Center Contact Material
- Beryllium Copper
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Includes
- 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule
- Filter Feature
- NO
- Weight
- 4.240011g
- Contact Termination
- Solder
- Kılıf / Paket
- SMB
- Mil Conformance
- NO
- Iec Conformance
- NO
- Kurşunsuz
- Lead Free
- Shield Termination
- Crimp
- Empedans
- 75Ohm
- Nominal Gerilim
- 500V
- Insertion Loss
- 0.6dB
- Frekans
- 4GHz
- Number Of Ports
- 1
- Yayın Yılı
- 2001
- Fastening Type
- Snap-On
- Connector Type
- Plug, Female Socket
- Fabrika Tedarik Süresi
- 9 Weeks
