Adet bazlı fiyat
- 1+ adet$5.99
- 10+ adet$5.65
- 100+ adet$5.33
- 500+ adet$5.03
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Frequencymax
- 11GHz
- Montaj
- Bulkhead, Front, Panel, Rear Side Nut
- Connector Type
- Jack, Female Socket
- Terminal
- Solder
- Radyasyon Dayanımı
- No
- Center Contact Material
- Phosphor Bronze
- Body Material
- Brass
- Montaj Tipi
- Panel Mount
- Body Finish
- Nickel
- Number Of Ports
- 1
- Min. Çalışma Sıcaklığı
- -65°C
- Contact Termination
- Solder
- Ambalaj
- Bulk
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Threaded
- Contact Plating
- Gold
- Housing Color
- Silver
- Center Contact Plating
- Gold
- Polarity
- Standard
- Shield Termination
- Solder
- Maks. Çalışma Sıcaklığı
- 165°C
- Connector Style
- TNC
- Nominal Gerilim
- 500V
- RoHS Durumu
- RoHS Compliant
- Cable Group
- RG-402 (.141 Semi Rigid)
- Body Plating
- Nickel
- Contact Materials
- Bronze
- Parça Durumu
- Active
- Uzunluk
- 29mm
- Insulation Materials
- Polytetrafluoroethylene
- Includes
- 5 pcs - 1 Connector, 1 Contact, 1 Insulator, 1 Lockwasher, 1 Nut
- Insertion Loss
- 0.18dB
- Frekans
- 11GHz
- Mating Cycles
- 500
- Orientation
- Straight
- Mounting Feature
- Bulkhead - Rear Side Nut
- Fabrika Tedarik Süresi
- 9 Weeks
- Yayın Yılı
- 2004
- Empedans
- 50Ohm
