Adet bazlı fiyat
- 1+ adet$8.01
- 10+ adet$7.56
- 100+ adet$7.13
- 500+ adet$6.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Cable Group
- RG-55, 142, 223, 400
- Sıra Sayısı
- 1
- Contact Materials
- Brass, Bronze
- Maks. Çalışma Sıcaklığı
- 155°C
- Mating Cycles
- 500
- Empedans
- 50Ohm
- Fabrika Tedarik Süresi
- 10 Weeks
- Yayın Yılı
- 2003
- Parça Durumu
- Active
- Insulator Color
- BLACK
- Frekans
- 11GHz
- Insertion Loss
- 0.18dB
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Montaj
- Cable, Free Hanging
- Connector Type
- Plug, Male Pin
- Housing Color
- Silver
- Center Contact Plating
- Gold
- Number Of Ports
- 1
- Ambalaj
- Bulk
- Contact Termination
- Crimp
- Total Number Of Contacts
- 36
- Dielectric Material
- Polyoxymethylene (POM) Acetal
- Nominal Gerilim
- 500V
- RoHS Durumu
- RoHS Compliant
- Number Of Conductors
- ONE
- Connector Style
- TNC
- Reference Standard
- UL
- Termination Type
- SOLDER
- Orientation
- Right Angle
- Weight
- 28.349523g
- Uzunluk
- 27.3mm
- Includes
- 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
- Insulation Materials
- THERMOPLASTIC
- Plating Thickness
- 30μin
- JESD-609 Kodu
- e3
- Center Contact Material
- Phosphor Bronze
- Body Material
- Brass
- Rated Current Signal
- 3A
- Body Finish
- Nickel
- Number Of Pcb Rows
- 1
