Adet bazlı fiyat
- 1+ adet$16.98
- 10+ adet$16.02
- 100+ adet$15.11
- 500+ adet$14.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Frekans
- 11GHz
- Insertion Loss
- 0.18dB
- Includes
- 4 pcs - 1 Connector, 1 Lockwasher, 1 Nut, 1 Solder Tag
- Mating Cycles
- 500
- Empedans
- 50Ohm
- Weight
- 15.999989g
- Fabrika Tedarik Süresi
- 9 Weeks
- Yayın Yılı
- 2009
- Orientation
- Straight
- Mounting Feature
- Bulkhead - Rear Side Nut
- Connector Style
- TNC
- Maks. Çalışma Sıcaklığı
- 165°C
- Nominal Gerilim
- 500V
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Brass
- Body Plating
- Nickel
- Ambalaj
- Bulk
- Contact Termination
- Solder Cup
- Number Of Ports
- 1
- Min. Çalışma Sıcaklığı
- -65°C
- Fastening Type
- Threaded
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Shield Termination
- Solder Tag
- Center Contact Plating
- Gold
- Housing Color
- Silver
- Contact Plating
- Gold
- Montaj
- Bulkhead, Front, Panel, Rear Side Nut
- Frequencymax
- 11GHz
- Radyasyon Dayanımı
- No
- Connector Type
- Receptacle, Male Pin
- Terminal
- Solder
- Center Contact Material
- Brass
- Body Finish
- Nickel
- Montaj Tipi
- Panel Mount
- Body Material
- Brass
