Adet bazlı fiyat
- 1+ adet$6.19
- 10+ adet$5.84
- 100+ adet$5.51
- 500+ adet$5.20
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- Contact Materials
- Bronze
- Nominal Gerilim
- 500V
- Çalışma Sıcaklığı
- -65°C~165°C
- Number Of Ports
- 1
- Kılıf / Paket
- 062
- Mating Cycles
- 500
- Frequencymax
- 4GHz
- Contact Termination
- Solder
- Insulation Materials
- Polytetrafluoroethylene
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Fabrika Tedarik Süresi
- 9 Weeks
- Uzunluk
- 25.55mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 8.479994g
- Parça Durumu
- Active
- Body Material
- Brass
- Mounting Feature
- Bulkhead - Front Side Nut
- Orientation
- Straight
- Connector Style
- BNC
- Empedans
- 75Ohm
- Fastening Type
- Bayonet Lock
- Center Contact Material
- Phosphor Bronze
- Montaj
- Bulkhead, Edge, Panel
- Yayın Yılı
- 2010
- Insertion Loss
- 0.2dB
- RoHS Durumu
- RoHS Compliant
- Center Contact Plating
- Gold
- Montaj Tipi
- Board Edge, End Launch; Panel Mount
- Ambalaj
- Bulk
- Connector Type
- Jack, Female Socket
