Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Radyasyon Dayanımı
- No
- Cable Group
- RG-402 (.141 Semi Rigid)
- Montaj
- Bulkhead, Front Side Nut, Panel
- Insertion Loss
- 0.2dB
- Depth
- 17.5mm
- Housing Color
- Gold
- Frequencymax
- 4GHz
- Number Of Ports
- 1
- Frekans
- 4GHz
- Yayın Yılı
- 2005
- Orientation
- Straight
- Center Contact Plating
- Gold
- Insulation Materials
- Polytetrafluoroethylene
- Connector Type
- Jack, Female Socket
- Ambalaj
- Bulk
- Montaj Tipi
- Panel Mount
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Mounting Feature
- Bulkhead - Front Side Nut
- Center Contact Material
- Phosphor Bronze
- Body Plating
- Gold
- Nominal Gerilim
- 500V
- Includes
- 6 pcs - 1 Connector, 1 Contact, 1 Gasket, 1 Insulator, 1 Lockwasher, 1 Nut
- Body Material
- Brass
- Kurşunsuz
- Lead Free
- Contact Plating
- Gold
- Connector Style
- BNC
- Weight
- 15.499988g
- Fabrika Tedarik Süresi
- 10 Weeks
- Maks. Çalışma Sıcaklığı
- 165°C
- Fastening Type
- Bayonet Lock
- Contact Termination
- Solder
- Contact Materials
- Bronze
- Empedans
- 50Ohm
- Uzunluk
- 26.3mm
- Terminal
- Solder
- Shield Termination
- Solder
- Min. Çalışma Sıcaklığı
- -65°C
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
