Adet bazlı fiyat
- 1+ adet$4.33
- 10+ adet$4.08
- 100+ adet$3.85
- 500+ adet$3.63
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Center Contact Material
- Phosphor Bronze
- Body Plating
- Nickel
- Body Material
- Zinc Alloy
- Nominal Gerilim
- 500V
- Contact Plating
- Gold
- Maks. Çalışma Sıcaklığı
- 165°C
- Fabrika Tedarik Süresi
- 9 Weeks
- Connector Style
- BNC
- Çalışma Sıcaklığı
- -65°C~165°C
- Fastening Type
- Bayonet Lock
- Contact Materials
- Bronze
- Contact Termination
- Solder
- Empedans
- 50Ohm
- Min. Çalışma Sıcaklığı
- -65°C
- Shield Termination
- Solder
- Dielectric Material
- Polypropylene (PP)
- Uzunluk
- 14.5mm
- Terminal
- Solder
- Mating Cycles
- 500
- Body Finish
- Nickel
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Radyasyon Dayanımı
- No
- Montaj
- Bulkhead, PCB, Panel, Through Hole
- Insertion Loss
- 0.2dB
- Depth
- 34.7mm
- Housing Color
- Silver, White
- Yayın Yılı
- 2013
- Frekans
- 4Hz
- Number Of Ports
- 1
- Center Contact Plating
- Gold
- Orientation
- Right Angle
- Frequencymax
- 1GHz
- Özellikler
- Board Lock
- Connector Type
- Jack, Female Socket
- Insulation Materials
- Polypropylene
- Ambalaj
- Bulk
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Mounting Feature
- Bulkhead
- Parça Durumu
- Active
