SFV4R-3STBE1HLF

Teknik Özellikler

Insulation Resistance

100MOhm

Fabrika Tedarik Süresi

14 Weeks

Contact Gender

FEMALE

Cable End Type

Notched

Housing Material

Polyamide (PA), Nylon, Glass Filled, Halogen Free

Height Above Board

0.071 1.80mm

Akım Değeri

500mA

Nominal Gerilim

50V

Filter Feature

NO

Contact Location

Bottom

Iec Conformance

NO

Özellikler

Solder Retention, Zero Insertion Force (ZIF)

Orientation

Horizontal

Yayın Yılı

2011

Actuatorcolor

Gray

Total Number Of Contacts

4

Nem Hassasiyeti (MSL)

1 (Unlimited)

Çalışma Sıcaklığı

-55°C~105°C

Mil Conformance

NO

Option

GENERAL PURPOSE

RoHS Durumu

RoHS Compliant

Material Flammability Rating

UL94 V-0

Contact Finish

Gold

Actuator Material

Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free

Pozisyon Sayısı

4

Sıra Sayısı

1

Parça Durumu

Active

Seri

SFV-R

Current Rating Amps

0.5A

Mixed Contacts

NO

Housing Color

Black

Ffc Fcb Thickness

0.33mm

Locking Feature

Slide Lock

Din Conformance

NO

Flat Flex Type

FPC

Mating Cycles

20

Montaj

Surface Mount

Pitch

0.020 0.50mm

Flammability Rating

UL94 V-0

Terminal

Solder
