Adet bazlı fiyat
- 1+ adet$0.41
- 10+ adet$0.39
- 100+ adet$0.37
- 500+ adet$0.35
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuator Material
- Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FPC
- Cable End Type
- Notched
- Actuatorcolor
- Gray
- Ambalaj
- Tape & Reel (TR)
- Mating Cycles
- 20
- Fabrika Tedarik Süresi
- 14 Weeks
- Seri
- SFV-R
- Contact Finish
- Gold
- Locking Feature
- Slide Lock
- Ffc Fcb Thickness
- 0.33mm
- Insulation Resistance
- 100MOhm
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 50V
- Height Above Board
- 0.071 1.80mm
- Iec Conformance
- NO
- Gender
- Receptacle
- Montaj
- Surface Mount
- Yayın Yılı
- 2011
- RoHS Durumu
- RoHS Compliant
- Din Conformance
- NO
- Akım Değeri
- 500mA
- Orientation
- Right Angle
- Total Number Of Contacts
- 12
- Pozisyon Sayısı
- 12
- Contact Location
- Top
- Contact Materials
- Phosphor Bronze
- Housing Color
- Black
- Terminal
- Solder
- Housing Material
- Polyamide (PA), Nylon, Glass Filled, Halogen Free
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Parça Durumu
- Active
- Mil Conformance
- NO
- Current Rating Amps
- 0.5A
- Filter Feature
- NO
- Sıra Sayısı
- 1
- Çalışma Sıcaklığı
- -55°C~105°C
- Pitch
- 0.020 0.50mm
