Adet bazlı fiyat
- 1+ adet$1.33
- 10+ adet$1.25
- 100+ adet$1.18
- 500+ adet$1.12
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Genişlik
- 9.57mm
- Contact Finish Mating
- Gold, GXT™
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Insulation Resistance
- 100GOhm
- Kurşunsuz
- Lead Free
- Terminal
- Solder
- Contact Materials
- Phosphor Bronze
- Akım Değeri
- 3A
- Contact Lengthmating
- 0.236 6.00mm
- Uzunluk
- 32.61mm
- Montaj
- Through Hole
- Contact Length Post
- 0.120 3.05mm
- Seri
- Quickie™
- Row Spacing Mating
- 0.100 (2.54mm)
- Özellikler
- Keying Slot
- Nominal Gerilim
- 500V
- Renk
- Blue
- Housing Material
- Thermoplastic
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Tube
- Min. Çalışma Sıcaklığı
- -65°C
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Pitch Mating
- 0.100 2.54mm
- Hole Diameter
- 1 mm
- Number Of Positions Loaded
- All
- Lead Length
- 3.05mm
- Contact Finish Post
- Tin
- Lead Pitch
- 2.54mm
- Contact Plating
- Gold
- RoHS Durumu
- RoHS Compliant
- Orientation
- Right Angle
- Insulation Materials
- Thermoplastic, Glass Filled
- Maks. Çalışma Sıcaklığı
- 125°C
- Fastening Type
- Push-Pull
- Sıra Sayısı
- 2
- Shrouding
- Shrouded - 4 Wall
- Reach Svhc
- No SVHC
- Number Of Contacts
- 20
- Housing Color
- Blue
