68016-121HLF

Teknik Özellikler

Housing Color

Black

Fastening Type

Push-Pull

Akım Değeri

3A

Number Of Contacts

21

Number Of Positions Loaded

All

Material Flammability Rating

UL94 V-0

Contact Finish Thickness Mating

30.0μin 0.76μm

Contact Lengthmating

0.230 5.84mm

Montaj

Through Hole

Contact Type

Male Pin

Maks. Çalışma Sıcaklığı

125°C

Contact Shape

Square

Max Voltage Rating Ac

1.5kV

Uzunluk

53.34mm

Mating Post Length

5.84mm

Shrouding

Unshrouded

Lead Length

3.05mm

Gender

Male

Montaj Tipi

Through Hole, Right Angle

Connector Type

Header

Nem Hassasiyeti (MSL)

1 (Unlimited)

Radyasyon Dayanımı

No

Insulation Height

0.095 2.41mm

Terminal

Solder

Contact Plating

GXT, Gold

Style

Board to Board

Seri

BERGSTIK® II

Insulation Color

Black

Depth

9.9mm

Pozisyon Sayısı

21

RoHS Durumu

RoHS Compliant

Contact Finish Mating

Gold or Gold, GXT™

Ambalaj

Bulk

Min. Çalışma Sıcaklığı

-65°C

Pitch

2.54mm

Parça Durumu

Active

Flammability Rating

UL94 V-0

Pitch Mating

0.100 2.54mm

Contact Materials

Phosphor Bronze

Housing Material

Thermoplastic
