Adet bazlı fiyat
- 1+ adet$0.26
- 10+ adet$0.25
- 100+ adet$0.23
- 500+ adet$0.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Gender
- Male
- Contact Length Post
- 0.120 3.05mm
- Seri
- BERGSTIK® II
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Flammability Rating
- UL94 V-0
- Max Voltage Rating Ac
- 1.5kV
- Housing Material
- Thermoplastic
- Lead Length
- 3.05mm
- Style
- Board to Board
- Overall Contact Length
- 0.450 11.43mm
- Insulation Color
- Black
- Fabrika Tedarik Süresi
- 8 Weeks
- Contact Finish Mating
- Gold or Gold, GXT™
- Montaj
- Through Hole
- Radyasyon Dayanımı
- No
- Row Spacing Mating
- 0.100 (2.54mm)
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Mating Post Length
- 5.84mm
- Insulation Resistance
- 5GOhm
- Maks. Çalışma Sıcaklığı
- 125°C
- Fastening Type
- Push-Pull
- Depth
- 4.83mm
- Insulation Height
- 0.100 2.54mm
- Housing Color
- Black
- Contact Materials
- Phosphor Bronze
- Pozisyon Sayısı
- 6
- Lead Pitch
- 2.54mm
- Contact Type
- Male Pin
- Contact Plating
- Gold
- Contact Shape
- Square
- Min. Çalışma Sıcaklığı
- -65°C
- Contact Lengthmating
- 0.230 5.84mm
- Material Flammability Rating
- UL94 V-0
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Ambalaj
- Bulk
- Uzunluk
- 7.62mm
- Number Of Positions Loaded
- All
- Renk
- Black
