Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Straight
- Connector Type
- FFC/FPC CONNECTOR
- Actuator Material
- Plastic, Glass Filled
- Depth
- 2.95mm
- Çalışma Sıcaklığı
- -55°C~105°C
- Current Rating Amps
- 0.5A
- Max Voltage Rating Dc
- 50V
- Contact Materials
- Phosphor Bronze
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 21
- Housing Material
- Plastic, Glass Filled
- Mil Conformance
- NO
- Seri
- SFV-S
- Sıra Sayısı
- 1
- Montaj
- Surface Mount
- Din Conformance
- NO
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Color
- Black
- Genişlik
- 2.95mm
- Insulation Resistance
- 100MOhm
- Fabrika Tedarik Süresi
- 17 Weeks
- Terminal
- Solder
- Radyasyon Dayanımı
- No
- Contact Finish
- Gold
- Max Voltage Rating Ac
- 50V
- Height Above Board
- 0.161 4.10mm
- Mating Cycles
- 20
- Cable End Type
- Straight, Tapered
- Contact Resistance
- 30mOhm
- Mixed Contacts
- NO
- Özellikler
- Zero Insertion Force (ZIF)
- Ffc Fcb Thickness
- 0.30mm
- Parça Durumu
- Active
- Total Number Of Contacts
- 21
- Uzunluk
- 15mm
- Iec Conformance
- NO
- Locking Feature
- Slide Lock
- Contact Gender
- FEMALE
- Flat Flex Type
- FFC, FPC
