Adet bazlı fiyat
- 1+ adet$0.76
- 10+ adet$0.72
- 100+ adet$0.68
- 500+ adet$0.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Renk
- Black
- Pitch
- 1.27mm
- Contact Lengthmating
- 0.120 3.05mm
- Number Of Positions Loaded
- All
- Contact Materials
- Copper Alloy
- Mating Post Length
- 3.05mm
- Housing Color
- Black
- Contact Finish Thickness Mating
- Flash
- Fabrika Tedarik Süresi
- 8 Weeks
- Pitch Mating
- 0.050 1.27mm
- Shrouding
- Unshrouded
- Row Spacing Mating
- 0.050 (1.27mm)
- Fastening Type
- Push-Pull
- Terminal
- Solder
- Contact Plating
- Gold
- Montaj Tipi
- Surface Mount
- Maks. Çalışma Sıcaklığı
- 85°C
- Style
- Board to Board
- Material Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Ambalaj
- Tape & Reel (TR)
- Number Of Contacts
- 10
- Contact Resistance
- 30mOhm
- Connector Type
- Header
- Contact Type
- Male Pin
- Parça Durumu
- Active
- Min. Çalışma Sıcaklığı
- -40°C
- Contact Finish Mating
- Gold
- Montaj
- Surface Mount
- Contact Finish Thickness Post
- 50.0μin 1.27μm
- Pozisyon Sayısı
- 10
- Özellikler
- Pick and Place
- Insulation Color
- Black
- Seri
- Minitek127® 1.27mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Thermoplastic
- Sıra Sayısı
- 2
- Contact Shape
- Square
- Uzunluk
- 6.35mm
- Max Voltage Rating Ac
- 125V
