20021121-00008C4LF

Teknik Özellikler

Pitch Mating

0.050 1.27mm

Number Of Positions Loaded

All

Pin Sayısı

8

Contact Resistance

30mOhm

Style

Board to Board

Orientation

Straight

Maks. Çalışma Sıcaklığı

85°C

Fastening Type

Push-Pull

Contact Plating

Gold

Insulation Color

Black

Pozisyon Sayısı

8

Stack Height

3mm

Seri

Minitek127® 1.27mm

Montaj

Surface Mount

Connector Type

Header

Parça Durumu

Active

Depth

3.4mm

RoHS Durumu

RoHS Compliant

Uzunluk

5.08mm

Max Voltage Rating Ac

125V

Reach Svhc

No SVHC

Shrouding

Unshrouded

Contact Finish Thickness Mating

10.0μin 0.25μm

Housing Color

Black

Fabrika Tedarik Süresi

7 Weeks

Contact Lengthmating

0.120 3.05mm

Pitch

1.27mm

Mating Post Length

3.05mm

Contact Materials

Copper Alloy

Renk

Black

Number Of Contacts

8

Ambalaj

Tape & Reel (TR)

Material Flammability Rating

UL94 V-0

Akım Değeri

1A

Row Spacing Mating

0.050 (1.27mm)

Montaj Tipi

Surface Mount

Terminal

Solder

Özellikler

Pick and Place

Contact Finish Thickness Post

50.0μin 1.27μm

Min. Çalışma Sıcaklığı

-40°C
