Adet bazlı fiyat
- 1+ adet$2.75
- 10+ adet$2.59
- 100+ adet$2.44
- 500+ adet$2.31
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Shape
- Square
- Pitch
- 1.27mm
- Overall Contact Length
- 0.309 7.86mm
- Orientation
- Straight
- Ambalaj
- Tube
- Number Of Contacts
- 50
- Pozisyon Sayısı
- 50
- Nominal Gerilim
- 125V
- Montaj
- Through Hole
- Parça Durumu
- Active
- Maks. Çalışma Sıcaklığı
- 85°C
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Length Post
- 0.091 2.30mm
- Mating Post Length
- 3.05mm
- Min. Çalışma Sıcaklığı
- -40°C
- Connector Type
- Header
- Insulation Materials
- Thermoplastic
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Seri
- Minitek127® 1.27mm
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 8 Weeks
- Insulation Height
- 0.098 2.50mm
- Contact Finish Thickness Post
- 50.0μin 1.27μm
- Contact Plating
- Gold
- Contact Resistance
- 30mOhm
- Insulation Color
- Black
- Style
- Board to Board
- Number Of Positions Loaded
- All
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Depth
- 3.4mm
- Uzunluk
- 31.75mm
- Shrouding
- Unshrouded
- Fastening Type
- Push-Pull
- Akım Değeri
- 50A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch Mating
- 0.050 1.27mm
- Max Voltage Rating Ac
- 125V
- Terminal
- Solder
- Contact Lengthmating
- 0.120 3.05mm
