Adet bazlı fiyat
- 1+ adet$2.30
- 10+ adet$2.17
- 100+ adet$2.04
- 500+ adet$1.93
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish Thickness Post
- 50.0μin 1.27μm
- Contact Plating
- Gold
- Contact Resistance
- 30mOhm
- Insulation Height
- 0.098 2.50mm
- Insulation Color
- Black
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Insulation Materials
- Thermoplastic
- Connector Type
- Header
- RoHS Durumu
- RoHS Compliant
- Seri
- Minitek127® 1.27mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Maks. Çalışma Sıcaklığı
- 85°C
- Parça Durumu
- Active
- Montaj
- Through Hole
- Min. Çalışma Sıcaklığı
- -40°C
- Contact Length Post
- 0.091 2.30mm
- Mating Post Length
- 3.05mm
- Row Spacing Mating
- 0.050 (1.27mm)
- Overall Contact Length
- 0.309 7.86mm
- Pitch
- 1.27mm
- Contact Shape
- Square
- Orientation
- Straight
- Nominal Gerilim
- 125V
- Ambalaj
- Tube
- Number Of Contacts
- 36
- Pozisyon Sayısı
- 36
- Montaj Tipi
- Through Hole
- Renk
- Black
- Housing Material
- Plastic
- Contact Materials
- Copper Alloy
- Contact Lengthmating
- 0.120 3.05mm
- Contact Finish Mating
- Gold
- Lead Length
- 2.3mm
- Housing Color
- Black
- Sıra Sayısı
- 2
- Gender
- Male
- Material Flammability Rating
- UL94 V-0
- Depth
- 3.4mm
- Uzunluk
- 22.86mm
- Shrouding
- Unshrouded
