Adet bazlı fiyat
- 1+ adet$1.65
- 10+ adet$1.56
- 100+ adet$1.47
- 500+ adet$1.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fastening Type
- Push-Pull
- Akım Değeri
- 1A
- Insulation Resistance
- 1GOhm
- Depth
- 3.4mm
- Uzunluk
- 16.51mm
- Shrouding
- Unshrouded
- Contact Finish Post
- Tin
- Terminal
- Solder
- Max Voltage Rating Ac
- 125V
- Pitch Mating
- 0.050 1.27mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Style
- Board to Board
- Flammability Rating
- UL94 V-0
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Yayın Yılı
- 2016
- Montaj Tipi
- Through Hole
- Renk
- Black
- Contact Materials
- Copper Alloy
- Housing Material
- Thermoplastic
- Contact Lengthmating
- 0.120 3.05mm
- Contact Finish Mating
- Gold
- Housing Color
- Black
- Lead Length
- 2.3mm
- Material Flammability Rating
- UL94 V-0
- Gender
- Male
- Sıra Sayısı
- 2
- Parça Durumu
- Active
- Maks. Çalışma Sıcaklığı
- 125°C
- Contact Gender
- Male
- Montaj
- Through Hole
- Min. Çalışma Sıcaklığı
- -55°C
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Length Post
- 0.091 2.30mm
- Mating Post Length
- 3.05mm
- Orientation
- Straight
- Pitch
- 1.27mm
- Contact Shape
- Square
- Overall Contact Length
- 0.309 7.86mm
- Nominal Gerilim
- 125V
