L777-RR-E-09-P

Teknik Özellikler

Reliability

COMMERCIAL

Shell Finish Thickness

100μin 2.54μm

Body Depth

0.161 inch

Yayın Yılı

2006

Insulation Materials

GLASS FILLED POLYETHYLENE

Connector Style

D-Sub

Nem Hassasiyeti (MSL)

1 (Unlimited)

Din Conformance

NO

Ambalaj

Bulk

Parça Durumu

Active

Çalışma Sıcaklığı

-55°C~125°C

Seri

RR

Contact Type

Signal

Contact Resistance

30mOhm

Rated Current Signal

5A

Sıra Sayısı

2

Dielectric Material

Polybutylene Terephthalate (PBT), Glass Filled

RoHS Durumu

RoHS Compliant

Özellikler

Grounding Indents

Contact Materials

NOT SPECIFIED

Contact Finish Mating

NOT SPECIFIED

Empty Shell

NO

Renk

Black

Fabrika Tedarik Süresi

6 Weeks

Iec Conformance

NO

Total Number Of Contacts

9

Mil Conformance

NO

Termination Type

CRIMP

Note

Contacts Not Included

Montaj Tipi

Free Hanging (In-Line)

Kurşunsuz Kodu

yes

Mounting Option1

LOCKING

Connector Type

Plug for Male Contacts

Shell Size Connector Layout

1 DE E

Insulation Resistance

1000000000Ohm

Flange Feature

Housing/Shell (Unthreaded)

Mixed Contacts

NO

Filter Feature

NO

Reference Standard

UL

Shell Material Finish

Steel, Tin Plated
