Adet bazlı fiyat
- 1+ adet$22.74
- 10+ adet$21.46
- 100+ adet$20.24
- 500+ adet$19.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Contact Finish Thickness
- 15.0μin 0.38μm
- RoHS Durumu
- RoHS Compliant
- Connector Style
- D-Sub
- Depth
- 18.39mm
- Housing Material
- Thermoplastic
- Özellikler
- Board Lock, Filter, Grounding Indents
- Shell Material Finish
- Steel, Tin Plated
- Seri
- FCE17
- Filter Feature
- YES
- Montaj
- Through Hole
- Contact Materials
- Phosphor Bronze
- Dielectric Material
- Thermoplastic, Glass Filled
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 7 Weeks
- Contact Finish
- Gold
- Yayın Yılı
- 2012
- Ambalaj
- Tray
- Mixed Contacts
- NO
- Material Flammability Rating
- UL94 V-0
- REACH Uyumluluk Kodu
- unknown
- Empty Shell
- NO
- Uzunluk
- 53.04mm
- Connector Type
- Plug, Male Pins
- Montaj Tipi
- Through Hole, Right Angle
- Kurşunsuz
- Lead Free
- Terminal
- Solder
- Iec Conformance
- NO
- Flange Feature
- Housing/Shell (4-40)
- Çalışma Sıcaklığı
- -40°C~85°C
- Pitch
- 2.76mm
- Din Conformance
- NO
- Backset Spacing
- 0.318 (8.08mm)
- Ul Flammability Code
- 94V-0
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.69.40.30
- Shell Finish
- TIN
- Total Number Of Contacts
- 25
- Number Of Ports
- 1
- Contact Type
- Signal
