9213 BK002

Teknik Özellikler

Dielectric Material

Solid Polyethylene (PE)

Number Of Conductors

1

Connector Support Type

WIRE AND CABLE

Fabrika Tedarik Süresi

7 Weeks

Direnç

0.006Ohm

Conductor Strand

7 Strands / 0.0296

Parça Durumu

Active

Vop Velocity Of Propagation

66

Uzunluk

500.0' 152.40m

Yayın Yılı

2006

Jacket Color

Black

Cable Types

Coaxial

Wire Gauge

13 AWG

Nem Hassasiyeti (MSL)

1 (Unlimited)

RoHS Durumu

ROHS3 Compliant

Stranding

7X.0296

Shielding

YES

Cable Group

RG-213

Shield Type

Braid

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Rated Voltage

3700V

Dielectric Diameter

0.285 (7.24mm)

Jacket Insulation Diameter

0.405 (10.29mm)

Onay Kuruluşu

MIL-C-17D

Conductor Material

Copper, Bare; Copper, Tinned

Shield Material

Copper, Bare

Çalışma Sıcaklığı

-15°C~80°C

Construction

STRANDED

Shield Coverage

96%

Empedans

50Ohm

Wire And Cable Name

COMMUNICATION CABLE
