9188A WH001

Teknik Özellikler

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Conductors

1

Cable Types

Coaxial

Cable Group

RG-188A

Dielectric Material

Polytetrafluoroethylene (PTFE)

Shield Coverage

94%

Shield Material

Copper, Silver Coated

Shield Type

Braid

Parça Durumu

Active

Empedans

50Ohm

Additional Feature

STANDARD: MIL-C-17D/69B

Jacket Insulation Diameter

0.105 (2.67mm)

Direnç

0.281Ohm

Dielectric Diameter

0.060 (1.52mm)

Conductor Strand

7 Strands / 0.0067

Shielding

YES

Çalışma Sıcaklığı

-55°C~200°C

RoHS Durumu

ROHS3 Compliant

Wire Gauge

25 AWG

Rated Voltage

900V

Jacket Insulation Material

Polytetrafluoroethylene (PTFE)

Onay Kuruluşu

CE; MIL

Vop Velocity Of Propagation

70

Conductor Material

Steel, Silver Coated

Yayın Yılı

2009

Construction

STRANDED

Uzunluk

1000.0' 304.80m

Jacket Color

White

Stranding

7X.0067

Fabrika Tedarik Süresi

34 Weeks

Wire And Cable Name

COMMUNICATION CABLE

Connector Support Type

WIRE AND CABLE
