9062A BK005

Teknik Özellikler

Cable Group

RG-62A

Conductor Strand

Solid

Dielectric Material

Solid Polyethylene (PE)

Shield Material

Copper, Tinned

Wire Gauge

22 AWG (0.32mm2)

Uzunluk

100.0' 30.48m

Connector Support Type

WIRE AND CABLE

Fabrika Tedarik Süresi

14 Weeks

Empedans

93Ohm

Cable Types

Coaxial

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Conductors

1

Rated Voltage

750V

Vop Velocity Of Propagation

84

Parça Durumu

Active

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Shielding

YES

Direnç

0.135Ohm

Çalışma Sıcaklığı

-20°C~80°C

Onay Kuruluşu

CE; MIL; UL

Jacket Insulation Diameter

0.242 (6.15mm)

RoHS Durumu

ROHS3 Compliant

Yayın Yılı

2009

Dielectric Diameter

0.146 (3.71mm)

Shield Coverage

95%

Shield Type

Braid

Jacket Color

Black

Conductor Material

Steel, Copper Coated

Wire And Cable Name

COMMUNICATION CABLE
