Fiyat için teklif alın
Adet ve teslim süresine göre fiyatlandırılır.
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Shield Coverage
- 95%
- Dielectric Diameter
- 0.146 (3.71mm)
- Parça Durumu
- Active
- Jacket Insulation Diameter
- 0.242 (6.15mm)
- Yayın Yılı
- 2006
- Jacket Color
- Black
- RoHS Durumu
- ROHS3 Compliant
- Cable Group
- RG-59
- Empedans
- 75Ohm
- Conductor Material
- Steel, Copper Coated
- Connector Support Type
- WIRE AND CABLE
- Çalışma Sıcaklığı
- -20°C~60°C
- Shield Type
- Braid
- Usage
- Network
- Fabrika Tedarik Süresi
- 12 Weeks
- Vop Velocity Of Propagation
- 66
- Dielectric Material
- Solid Polyethylene (PE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 500.0' 152.40m
- Conductor Strand
- Solid
- Wire Gauge
- 22 AWG (0.32mm2)
- Shield Material
- Copper, Bare
- Cable Types
- Coaxial
- Jacket Insulation Material
- Poly-Vinyl Chloride (PVC)
