65103CY SL001

Teknik Özellikler

Number Of Conductors

3

Shielding

YES

Onay Kuruluşu

CE; CSA; UL; VDE

Conductor Material

Copper, Bare

Gerilim

600V

Parça Durumu

Active

Jacket Insulation Thickness

0.0700 1.778mm

Jacket Insulation Diameter

0.630 (16.00mm)

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

RoHS Durumu

ROHS3 Compliant

Construction

STRANDED

Jacket Color

Slate

Cable Types

Multi-Conductor

Shield Material

Copper, Tinned

Ambalaj

Spool

Conductor Insulation

Poly-Vinyl Chloride (PVC)

Fabrika Tedarik Süresi

8 Weeks

Yayın Yılı

2008

Connector Support Type

WIRE AND CABLE

Insulation Materials

POLYVINYL CHLORIDE

Wire And Cable Name

FLEXIBLE CORD AND FIXTURE WIRE

Özellikler

Biological Compatibility

Seri

Xtra-Guard® Flex

Operating Temperature Min

-40°C

Ratings

ISO 10993, UL Style 2587

Nem Hassasiyeti (MSL)

1 (Unlimited)

Shield Type

Braid

Wire Gauge

10 AWG

Shield Coverage

85%

Uzunluk

1000.0' 304.8m

Operating Temperature Max

90°C

Conductor Strand

105/30
