6453 BK005

Teknik Özellikler

Cable Types

Multi-Conductor

Ambalaj

Spool

Shield Material

Aluminum; Copper, Tinned

Conductor Insulation

High Density Polyethylene (HDPE)

Özellikler

Drain Wire

Parça Durumu

Active

Fabrika Tedarik Süresi

14 Weeks

Yayın Yılı

2011

Connector Support Type

WIRE AND CABLE

Shield Coverage

100%, 65%

Shield Type

Foil, Braid

Conductor Strand

7/30

Uzunluk

100.0' 30.5m

Gerilim

300V

Wire Gauge

22 AWG

Nem Hassasiyeti (MSL)

1 (Unlimited)

Çalışma Sıcaklığı

-20°C~60°C

Number Of Conductors

2 (1 Pair Twisted)

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Jacket Insulation Thickness

0.0420 1.067mm

Conductor Material

Copper, Tinned

RoHS Durumu

ROHS3 Compliant

Jacket Color

Black

Jacket Insulation Diameter

0.284 (7.21mm)
