6017C SL002

Teknik Özellikler

Number Of Conductors

24 (12 Pair Twisted)

Shield Type

Foil

Gerilim

300V

Conductor Material

Copper, Tinned

RoHS Durumu

ROHS3 Compliant

Yayın Yılı

2006

Jacket Color

Slate

Jacket Insulation Diameter

0.503 (12.78mm)

Conductor Insulation

Polypropylene (PP)

Ambalaj

Spool

Conductor Strand

7/30

Nem Hassasiyeti (MSL)

1 (Unlimited)

Connector Support Type

WIRE AND CABLE

Jacket Insulation Material

Poly-Vinyl Chloride (PVC)

Özellikler

Drain Wire

Uzunluk

500.0' 152.4m

Shield Coverage

100%

Jacket Insulation Thickness

0.0480 1.219mm

Çalışma Sıcaklığı

-20°C~60°C

Fabrika Tedarik Süresi

5 Weeks

Parça Durumu

Active

Wire Gauge

22 AWG

Cable Types

Multi-Pair

Shield Material

Aluminum

Usage

Communication, Control
