P50E-026P1-SR1-EA

Teknik Özellikler

Insulation Color

Black

Seri

Pak 50, P50E

Contact Finish Thickness Mating

10.0μin 0.25μm

Contact Length Post

0.118 3.00mm

Fabrika Tedarik Süresi

9 Weeks

Ambalaj

Bulk

Maks. Çalışma Sıcaklığı

85°C

Contact Finish Post

Gold

Nem Hassasiyeti (MSL)

1 (Unlimited)

Insulation Materials

Polyamide (PA), Nylon, Glass Filled

Contact Plating

Gold

Yayın Yılı

2006

Montaj

Through Hole

Akım Değeri

500mA

RoHS Durumu

RoHS Compliant

Style

Board to Board or Cable

Material Flammability Rating

UL94 V-0

Gender

Male

Contact Finish Mating

Gold

Contact Finish Thickness Post

Flash

Shrouding

Shrouded - 4 Wall

Fastening Type

Latch Holder

Çalışma Sıcaklığı

-55°C~85°C

Sıra Sayısı

2

Pitch Mating

0.050 1.27mm

Parça Durumu

Active

Min. Çalışma Sıcaklığı

-55°C

Renk

Black

Current Rating Amps

0.5A

Connector Type

Plug

Contact Materials

Copper Alloy

Housing Material

Nylon

Terminal

Solder

Pozisyon Sayısı

26

Contact Type

Center Strip Contact

Montaj Tipi

Through Hole, Right Angle

Number Of Contacts

26

Flammability Rating

UL94 V-0

Number Of Positions Loaded

All

Pitch

1.27mm
