Adet bazlı fiyat
- 1+ adet$3.00
- 10+ adet$2.83
- 100+ adet$2.67
- 500+ adet$2.52
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Copper Alloy
- Voltage Rated Ac
- 350V
- Sıra Sayısı
- 2
- Contact Finish Post
- Tin
- Nominal Gerilim
- 1kV
- Number Of Poles
- 16
- Contact Finish Mating
- Gold
- Insulation Height
- 0.340 8.64mm
- Depth
- 24.6mm
- Contact Finish Thickness Post
- 200.0μin 5.08μm
- Row Spacing Mating
- 0.100 (2.54mm)
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole, Right Angle
- Pitch Mating
- 0.100 2.54mm
- Contact Length Post
- 0.112 2.84mm
- Current Rating Amps
- 1.75A
- Contact Shape
- Square
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Male
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.240 6.10mm
- Orientation
- Right Angle
- Housing Color
- Black
- Insulation Color
- Black
- Seri
- 3000
- Fabrika Tedarik Süresi
- 6 Weeks
- Renk
- Black
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Housing Material
- Polychlorinated
- Pitch
- 2.54mm
- Contact Type
- Male Pin
- Uzunluk
- 39.75mm
- Yayın Yılı
- 2005
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Max Current Rating
- 2A
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Contact Plating
- Gold
- Terminal
- Solder
