Adet bazlı fiyat
- 1+ adet$1.48
- 10+ adet$1.40
- 100+ adet$1.32
- 500+ adet$1.25
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Seri
- D3000
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Length Post
- 0.112 2.84mm
- Contact Finish Mating
- Gold
- Insulation Color
- Black
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Pitch Mating
- 0.100 2.54mm
- Parça Durumu
- Active
- Shrouding
- Shrouded - 4 Wall
- Connector Type
- Header
- Sıra Sayısı
- 2
- Contact Lengthmating
- 0.240 6.10mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Ambalaj
- Tray
- Contact Finish Post
- Tin
- Montaj Tipi
- Through Hole, Right Angle
- Yayın Yılı
- 2009
- Pin Sayısı
- 14
- Pozisyon Sayısı
- 14
- Number Of Positions Loaded
- All
- Row Spacing Mating
- 0.100 (2.54mm)
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Keying Slot, Mounting Flange
- Fastening Type
- Push-Pull
- Insulation Materials
- Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
- Current Rating Amps
- 1.75A
- Insulation Height
- 0.340 8.64mm
- Contact Materials
- Brass
- Material Flammability Rating
- UL94 V-0
- Contact Type
- Male Pin
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Çalışma Sıcaklığı
- -55°C~105°C
- Terminal
- Solder
