Adet bazlı fiyat
- 1+ adet$5.33
- 10+ adet$5.03
- 100+ adet$4.75
- 500+ adet$4.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -40°C~105°C
- Pozisyon Sayısı
- 50
- Insulation Height
- 0.217 5.51mm
- Contact Shape
- Square
- Özellikler
- Keying Slot
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Contact Finish Mating
- Gold
- Fabrika Tedarik Süresi
- 8 Weeks
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2008
- Parça Durumu
- Active
- Insulation Materials
- Thermoplastic
- Ambalaj
- Tray
- Montaj Tipi
- Through Hole, Right Angle
- Number Of Contacts
- 50
- RoHS Durumu
- RoHS Compliant
- Pitch Mating
- 0.079 2.00mm
- Contact Finish Thickness Mating
- Flash
- Contact Length Post
- 0.118 3.00mm
- Current Rating Amps
- 1A
- Montaj
- Through Hole
- Number Of Positions Loaded
- All
- Fastening Type
- Push-Pull
- Gender
- Male
- Contact Plating
- Gold
- Akım Değeri
- 1A
- Sıra Sayısı
- 2
- Housing Material
- Thermoplastic
- Style
- Board to Board
- Insulation Color
- Black
- Seri
- 957
- Row Spacing Mating
- 0.079 (2.00mm)
- Contact Materials
- Copper Alloy
- Contact Type
- Male Pin
- Renk
- Black
- Pitch
- 2.0066mm
- Contact Finish Post
- Tin
- Connector Type
- Header
- Terminal
- Solder
- Shrouding
- Shrouded - 4 Wall
